22 Exoskeletons For Work and Industry Into 6 Categories

Exoskeletons For Industry And Work Featured Image

Wearable robotics designed to be used in an industrial setting is the fastest growing field of exoskeleton research.  Exoskeletons for work and industry can be used at construction sites, dry-docks, factories, warehouses and even surgical rooms.  In the most recent presentation by the Wearable Robotics Association, Dr. Joseph Hitt described exoskeletons for manufacturing and construction as the “low hanging fruit” of the exoskeleton market.  His argument is that medical facilities have a limited budget for rehabilitation robots and a dozen companies with years of experience already exist.  In contrast, there are few exoskeletons for work and large industrial companies could buy millions of units for their workers in the coming decades.

Exoskeletons for industry and the workplace offer three main advantages:  Reduction in work related injuries, saving billions of dollars in medical fees, sick leave and lawsuits.  Lowered worker fatigue, leading to increased worker alertness, productivity and work quality.  The ability to keep quality and experienced personnel past their physical prime in the work force longer.

Before listing over a dozen exoskeleton products and research projects that are meant to be used in the workplace, let’s separate them into categories based on what they are meant to do.

Exoskeletons for work and industry can be separated into 6 categories:

  • Tool Holding Exoskeletons: these exoskeletons consist of a spring-loaded arm such as the zeroG mechanical arm that supports a heavy tool on one end and is connected to a lower body exoskeleton and a counterweight.  The exoskeleton is usually passive but there is at least one prototype with motors in the legs.  The weight of the tool is transmitted directly into the ground.
  • Chairless Chairs: these are lightweight exoskeletons worn on top of work pants which can stiffen and lock in place.  This can decrease fatigue while crouching or standing in the same position for an extended period of time.
  • Back Support: these exoskeletons can maintain the correct posture of the back while bending down to perform a lift.  They can also reduce the load on the back muscles or even on the spine while bending down.
  • Powered Gloves: mechanized gloves that can help workers with a weak grasp gain a stronger hold on tools.  There are also devices that are used in reverse, in which workers that have trouble naturally opening some fingers on the hand to grasp tools can have them opened by an exoskeleton glove.
  • Full Body Powered Suits: up until a few years ago it was believed that large, full body powered suits will be used for work and industry.  Now almost all developers have switched to smaller, specialized exoskeletons but there are still ongoing projects in this area.
  • Additional / Supernumerary Robotics: exoskeletons that provide a second pair of hands.  This is by far the most ambitious wearable robotics project for work and industry.  Two or more additional, powered arms controlled by the wearer are used to hold tools or materials in place.  Technically, tool holding exoskeletons are also supernumerary, however the arms are always passive, spring loaded and can’t be independently controlled.

Now that we have categorized the exoskeletons for work and industry by what they are trying to achieve here are some examples of each type:

Fortis Exoskeleton By Lockheed Martin In Action, 2014, DesignBoom.com

Fortis Exoskeleton By Lockheed Martin In Action, 2014, DesignBoom.com

1. Tool Holding Exoskeletons:






Noonee Chairless Chair

Noonee Chairless Chair

2. Chairless Chairs:

  • Noonee Chairless Chair Wearable Ergonomic Device
  • Body Weight Assist Device by Honda
  • Archelis by Wearable Chair

The design blog, Core 77 has several articles on the Noonee chairless chair and its history going back all the way to the early 1900s.


V-22 Ergoskeleton by StrongArm Technologies

V-22 Ergoskeleton by StrongArm Technologies

3. Back Support:

  • V-22 Ergoskeleton by StrongArm Technologies
  • Laevo by Laevo
  • MAX by SuitX (formally US Bionics)
  • Hip Auxiliary Muscle Suit by Innophys
  • Hal for Labor Support Lumber by CYBERDYNE
  • AWN-03 by Panasonic by ActiveLink




SEM Glove Bioservo

SEM Glove Bioservo

4. Powered Gloves:








Glauco Ferrari, integrazione elettrica. Operatore esperto del "Body Extender", PERCRO Lab

Glauco Ferrari, integrazione elettrica. Operatore esperto del “Body Extender,” PERCRO Lab

5. Full Body Power Suits:

  • Dual-Arm Power Amplification Robot, MS-2 by Panasonic – ActiveLink
  • Prototype Shipyard Exoskeleton by Daewoo S&M Engineering
  • Body Extender by PERCRO Lab
  • HULC by Lockheed Martin and Ekso Bionics
  • XOS 2 by Sarcos / Raytheon








Supernumerary Robotics Limbs (SRL) Concept, MIT

Supernumerary Robotics Limbs (SRL) Concept, MIT

6. Supernumerary Robotic Arms:
