Otherlab Orthotics – A Fundamental Jump in Technology

Inflatable Soft Exoskeleton: orthotics.otherlab.com Inflatable Soft Exoskeleton: orthotics.otherlab.com

Sometimes there are exoskeleton videos that manage to completely fly under the radar.  The Otherlab Orthotics Show and Tell is exactly one of those videos (below)!  In it, presenter Tim Swift addresses the main issue with wearable robotics: Reducing The Cost Of Exoskeleton Devices.  Tim Swift’s solution is to go with soft exoskeletons and exosuits.  Swift is one of the original designers of the Ekso and worked at Ekso Bionics from 2008 to 2013.  Swift left Ekso Bionics to co-found Otherlab Orthotics in a quest to create a light and inexpensive inflatable exoskeleton that can be used in multiple environments.

Tim Swift offers a unique perspective, from inside one of the oldest exoskeleton companies.  He has acknowledged that current exoskeleton technology isn’t making much progress.  Current full body and lower extremities exoskeletons are very heavy and expensive and it will take decades of optimization of materials, motors and batteries to reduce their cost.  Swift and Otherlab Orthotics are attempting to reduce the weight, complexity and price of exoskeletons by developing air powered soft exosuits.  This approach may not necessarily succeed: traditional air compressors are large, bulky and power hungry.  The compressed air needs to be controlled using gauges and valves which are heavy, loud and sometimes sluggish.

Does Tim Have A Point!?

Lack of Proliferation of Exoskeleton Technology, Screenshot From Otherlab Orthotics Show And Tell, 2015

Lack of Proliferation of Exoskeleton Technology, Screenshot From Otherlab Orthotics Show And Tell, 2015

In his presentation, Tim Swift claims that exoskeleton technology needs to go through a profound change.  Is he just a disgruntled Ekso Bionics employee or does he have a point?  If you consider the first modern exoskeleton to be the Active Suit made in 1978 by Mihailo Pupin Institute then exoskeletons really haven’t conquered much ground in nearly 37 years.  Tim Swift appears to be a visionary who sees exoskeletons becoming a staple of every household, much like a bicycle or TV.  Looking at the slide from his presentation (above) we can see that powered suits have made inroads into only one subsection of the medical field.  This is a very slow progress considering the dozens of companies and universities that have spent decades working on solid frame powered suits.

Otherlab Orthotics is not the only startup working on soft exoskeletons.  Prestigious universities such as Harvard have been researching soft exoskeletons, as has DARPA.  One of the most successful exoskeleton products, in terms of units sold, is the Ski Mojo which also deviates from the classical hard frame exoskeletons.  In recent news, Strong Arm Tech’s V22 which is a motorized posture control vest, caught the attention of the very large company 3M.  Not everyone though agrees that the future of exoskeleton technology lies in a fundamental change (in this case, removing the solid mechanical frame).  For example, Homayoon Kazerooni, co-founder of Ekso Bionics who has also left to start his own company, US Bionics  is betting that exoskeletons can be made cheaper by using more readily available components and removing unnecessary functions.

What air muscles is Otherlab Orthotics using?

Otherlab Orthotics Remote Center Actuator

Otherlab Orthotics Remote Center Actuator

The air muscles featured in this video are called pneumatics. This groundbreaking technology was developed under DARPA’s Maximum Mobility and Manipulation program during an $800k effort (taken from Orthotics’ sister company: Pneubotics).  Pneumatics can be driven using either a liquid or compressed gas and are an air tight “bladder” covered by a harder nylon material similar to backpack fabric.  The main advantage of pneumatics is the elimination of drive trains, bearings, axels, belts and sliders resulting in a significantly simpler device.

What is Otherlab?

Otherlab is a privately held research incubator located in the Mission District of San Francisco, CA.   This makes Otherlab Orthotics the third exoskeleton company with a headquarters in the SF Bay Area.

Tim Swift and Otherlab Orthotics could be onto something big and hopefully will be releasing more information on their research soon!  In the mean time, there is an interview with Tim Swift from 2014 on slashdot.org website that offers a bit more insight on the exosuit.

10 Comments on Otherlab Orthotics – A Fundamental Jump in Technology

  1. Kimberly Johnson // October 1, 2015 at 4:23 pm // Reply

    My son is a C5 incomplete (ASIA C) quadriplegic from a diving accident in July 2005. He has done exercise based therapy and was a gifted athlete prior to his injury. Clearly, this is an issue that is close to the hearts of those that know and love him. I’m very interested in following this technology as it evolves and would like to know how to connect my son with any opportunities that might arise.

    • Dear Kimberly, I am really sorry about your son’s driving accident. This technology is in the very early stages of development. Currently the only FDA approved exoskeleton for home use is the ReWalk but it comes at a cost of over $60,000 just for the device and it requires constant supervision to use. A more realistic approach would be to find a private rehabilitation gym that has an exoskeleton. Many rehabilitation gyms are either purchasing wearable robotic devices or have them on trial loans and have professionals that know how to use them. An alternative could be to have your son participate in a clinical study. You can monitor ClinicalTrials.gov (https://clinicaltrials.gov/ct2/home) and see if something comes up in your area. Furthermore, the Ekso Bionics and ReWalk Robotics websites have updated lists of Centers that use their technology. -Bobby

  2. Hello,

    it certainly looks impressive, great job guys (y). But I am curious about how you would provide “energy” to the exoskeleton… Aren’t you changing the problem, so instead of a bulky battery you will have a (bulky?) compressor beside your exoskeleton which will provide you compressed air (energy)? I totally understand that your main goal is to change exoskeleton’ structure so you have a simple lightweight solution… but the compressor?

    • Hello, I have worked with the large compressors used in robots and they are large, bulky, noisy, heat up and vibrate. Clearly not something you would want on your body! Inflatable exoskeleton prototypes all seem to work at very low PSI ranges (5-15 PSI). I can’t speak directly about Otherlab Orthotics but I have seen at least 2 different labs now developing small, compact compressors that do not have the same drawbacks as their regular larger counterparts. At least one other inflatable exo operates off of replaceable compressed gas cartridges. Hopefully, between smaller custom built compressors and replaceable cartridges the issue can be mitigated enough for prototypes to keep pouring in!

  3. What does ‘On contract to build Iron Man’ mean?

    I think he meant to say, on track – I see no mentions of any contracts on the Otherlab! website

  4. Oh I see, a nearly 3 million contract from DARPA – my confusion.

  5. WASHINGTON, March 25 — Defense Advanced Research Projects Agency (Other Defense Agencies), Contracts Management Office, has awarded a $998,607 and not to exceed option $2,948,591 federal contract on March. 25 for “DARPA-BAA-15-35 Biological Technologies.”

    https://www.highbeam.com/doc/1P3-4000208541.html

    Sorry for saying it was 3 million without clarification, I didn’t read it fully.
